700T Fully Revolving Crane Semi-Submersible Vessel for Sale - 2020 Built, SHER Worldwide

General Specification

• Type: 700t Full-Revolving Semi-submersible Vessel

• Port of Registry: Ningbo, P.R. China

• Navigation Area: Unlimited

• Self-Propelled: No

• Emission Standards: NOx Tier II

• Flag: P.R. China

• Year: 2020

• Builder: Ningbo Zhenhe Shipbuilding Co., Ltd

• Designer: Shanghai Engineering Co., LTD

• Classification: CCS

• Notation: ? CSA Pontoon Barge Semi-Submersible Vessel / Floating Crane, R1, Lifting Appliance, In-Water Survey

Principal Particulars

• Overall Length (L.O.A): Approximately 141.55m

• Length (L): 86.00m

• Breadth (B): 36.00m

• Moulded Depth (to Jacking Deck): 6.00m

• Design Draft: 4.00m

• Maximum Submergence (Including Tidal Variation): 24.00m

• Distance from Baseline to Safety Deck: 24.50m

• Distance from Baseline to Top Deck: 28.50m

• Bow Tower Length: 30.00m

• Bow Tower Width: 7.80m

• Bow Tower Height (from Jacking Deck to Deck): 22.50m

• Stern Tower Length: 18.00m

• Stern Tower Width: 7.80m

• Stern Tower Height (from Jacking Deck to Deck): 22.50m

• Freeboard at Maximum Submergence (to Top Deck): 4.50m

• Frame Spacing: 2.00m

• Longitudinal Girder Spacing: 0.60m

• Crew Capacity: 40 persons

• Endurance: 20 days

Safety Equipment

• Liferafts: 2x 20-Person Throw-overboard Inflatable Liferaft

• Liferaft Davit: 1

Accommodation

• Total Capacity: 40 persons

• Cabin Layout:

  • 1-Person Cabins: 4

  • 2-Person Cabins: 4

  • 4-Person Cabins: 7

Main Capacity

• Ballast Tank: 26,062.90m³

• Fuel Oil Tank: 108.00m³

• Clearwater Tank: 105.00m³

• Freshwater Tank: 300.00m³

Crane Hook Lifting Parameters

• Main Hook:

  • Lifting Capacity: 700t

  • Working Radius: 24m

  • Hoisting Speed: 4m/min

• Main Hook (Alternative):

  • Lifting Capacity: 600t

  • Working Radius: 28m

  • Hoisting Speed: 4m/min

• Auxiliary Hook:

  • Lifting Capacity: 100t

  • Working Radius: 48m

  • Hoisting Speed: 10m/min

• Rigging Hook:

  • Capacity: 10T x 2 Sets (for personnel lifting: 2t)

  • Working Radius: Min: 23.2m, Max: 60m

  • Hoisting Speed: 6.5m/min

Hook Performance Parameters

• Main Hook Lifting Height:

  • Above Deck: 140 m

  • Below Deck: 25 m

• Main Hook Max. Revolving Radius: 60 m

• Main Hook Min. Revolving Radius: 23.2 m

• Auxiliary Hook Lifting Height:

  • Above Deck: 150 m

  • Below Deck: 25 m

• Auxiliary Hook Max. Revolving Radius: 67.2 m

• Auxiliary Hook Min. Revolving Radius: 27.2 m

Boom System

• Revolving Speed: Full Load: 0.15 r/min, No Load: 0.25 r/min

• Revolving Range: 360°

• Luffing Speed: Approximately 32 minutes (boom luffing from -4° to max elevation angle 82° under no-load condition)

• Luffing Angle: Operational: 62.9° ~ 83°, Non-operational: -4° ~ 62.9°

Generator

• Main Generator Sets: Diesel Engine, 3x 580kW @1500RPM

• Main Generators: 2x 500kW @1500RPM

• Harbor Generator Set: Diesel Engine, 2x 90kW @1500RPM

• Harbor Generators: 2x 75kW @1500RPM

Winches

• Electric Three-Speed Positioning Winch: Quantity: 5, Weight: 12T, Rated Pulling Force: 350 kN, Supporting Load: 1000 kN, Rated Speed: 9m/min, No-Load Speed: ≥15/min, Wire Rope Diameter: ∅46mm, Rope Capacity: 600m

• Electric Three-Speed Positioning Winch (Also Serves as a Sailing Anchor System): Quantity: 1, Weight: 15T, Rated Pulling Force: 350 kN, Supporting Load: 2900kN, Rated Speed: 9m/min, No-Load Speed: 15/min, Wire Rope Diameter: ∅76mm, Rope Capacity: 600m

Ballast System

• Number of Ballast Tanks: 6

• Number of Ballast Pumps: 4

• Ballast Pump Capacity: 1800m³/h

Additional Information

• Asking Price: Revealed to serious and committed buyers only upon full business and background disclosure.

• Commitment Required:
  To ensure mutual respect for time and resources, we require:

  1. Clear Budget Levels: Aligned with international market rates.

  2. End Buyer Background Disclosure: Serious named buyers only.

• Contact Information:
  Email: "Mr.Sher (VESSELS) Singapore - Malaysia - S&P" sw@sher-worldwide.com / sherworldwidetrading@gmail.com

• Terms & Conditions:
  T&Cs apply as per website. Details believed correct at the time of advertising. Vessels/items offered “as is where is,” subject to prior sale or withdrawal. SW not liable for errors or omissions and reserves the right to amend contents without notice.
